Lazer Line Static White Up+Down Suspended Lighting System ID: LZUD-6W-5-24KZ-24KZ-WH
Lazer Line Static White Up+Down Suspended Lighting System 284 Ceiling Lighting PureEdge Lighting

Lazer Line Static White Up+Down Suspended Lighting System

By Derek Porter and Gregory Kay, for PureEdge Lighting

Lazer Line Static White Up+Down Suspended Lighting System

By PureEdge Lighting

$799.20 - $2,714.40

Free Shipping Icon

Usually leaves warehouse in 4-6 weeks

Based upon stock availability.

Accessories Not Included. See accessories here.

$799.20

SPEC #: EDG974679 | ID: LZUD-6W-5-24KZ-24KZ-WH

3D View

Explore 3D

Lazer Line Static White Up+Down Suspended Lighting System

SPEC #: EDG974679

ID: LZUD-6W-5-24KZ-24KZ-WH

Lazer Line is a 24VDC Direct/Indirect (uplight and downlight) LED Lighting System providing general illumination for architectural applications. The field-cuttable dual strip channel is sold in 5 foot increments in 6 watts (2x3.3 watts) or 10 watts (2x4.4 watt) per foot. The 6 watt option allows a maximum length of 30 feet with two power feeds at one end or 60 feet with two power feeds at both ends. The 10 watt option allows a maximum length of 20 feet with two power feeds at one end or 40 feet with two power feeds at both ends. Finish in White or Satin Black. System requires a Universal (UNI) power supply (TRIAC/ELV/0-10V dimming). May be switched separately. Product is built to order.

System includes Lazer Line Channel (LZUD), Lazer Line Tape, and one pair of turnbuckles. Additional turnbuckles needed and standoff(s) are sold separately.

Note:
A Universal (UNI) power supply is required and sold separately.

Available Options

Finish: White

Specifications

    • Finish: White
    • Option: 2400K Up / 2400K Down
    • Size: 60"L x 0.44"W
    • Dimmer: Low Voltage Electronic
    • Materials: Aluminum
    • Lamp Source: LED
    • Bulb:
      5 x LED/6W/24V LED
      Integrated LED module
    • Total Wattage: 30 watts
    • Lamp Color: 2400K
    • Lamp Life: 50000 hours
    • ETL

      ETL

    • Damp Location

      Damp Location

    • Title 24 (JA8)

      Title 24 (JA8)

    • Prop 65 Warning for California Residents This product can expose you to chemicals, which are known in the State of California to cause cancer, birth defects or other reproductive harm. For more information go to https://www.p65warnings.ca.gov/.
      Brand Logo

      A merge of Pure Lighting (recessed architectural lighting systems) and Edge Lighting (minimalist suspensions and wall fixtures), Chicago-based PureEdge Lighting offers a robust catalog of innovative lighting systems, scalable to any size space. Award-winning product collections like TruLine and Lazer Line create minimalist lines of light both in and out of the drywall, serving as tools that allow architects and designers to unleash their creativity ... let the drywall be your canvas! TruTrack recessed track lighting takes an existing system, and updates it for the modern era in clean, seamless fashion. Another award-winning, innovative light system - Pipeline Modular is the perfect solution for today's urban lofts and open offices, consisting of rounded bars of light that can be pieced together to weave within the network of ducts and pipes found in today's open ceilings. Other collections - like Tie Stix, Glide and Pix Sticks - deliver linear suspensions perfectly suited for today's modern kitchens and lobbies. In the bathroom, vanity lights and LED lit mirrors bring future technology like Warm Dim and Tunable White to an environment that demands personalization and mood-setting functionality. With so many options, it's no wonder PureEdge Lighting has become the go-to name for high-end residences, offices, retail and more. From projects with Delta and Lyft to Chicago's-own Merchandise Mart, PureEdge Lighting knows a thing or two about illuminating today's best - and brightest - environments.
