Channel Neon Outdoor .5 inch Flat Lens Tunable White 24V
By Gregory Kay, for PureEdge Lighting
Channel Neon Outdoor .5 inch Flat Lens Tunable White 24V
By Gregory Kay, For PureEdge Lighting
$377.00 - $610.00
Length:
60”
Usually leaves warehouse in 2-3 weeks
Based upon stock availability.
$377.00
+ FREE SHIPPING
SPEC #: EDG1530001 | ID: CN-F5-5W-60-2K6K-ECAW
Channel Neon Outdoor .5 inch Flat Lens Tunable White 24V
SPEC #: EDG1530001
ID: CN-F5-5W-60-2K6K-ECAW
Designed by Gregory KayRead Bio
Channel Neon is the Flex Neon fixture shipped within a channel for ease of installation. Channel Neon comes with a 0.5 inch wide flat lens, offering superior color rendering while creating uniform illumination without visible diodes. May be surface or flush mounted.
Available in Tunable White 2000K-6500K (2K6K) at 5 watts per foot from 6 to 120 inch max. Tunable White allows for independent control and adjustment of color temperature and intensity from 2000K (sunset) through 6500K (daylight white). Tunable White is ideal for residential spaces by allowing the user to achieve a warm glow during the golden hours of the early mornings and evenings.
Tunable White can be used with two 0-10V dimmers (one for intensity and one for color temperature), or a DMX power supply which requires the proprietary Tunable White Controller (CDMX-1) for fast and accurate adjustment with three pre-set scenes.
Features End Input Wire Leads and End Cap Output Wire Leads (no feed thru) with wet location Barrel Connector cable leads.
Required 0-10V power supplies or DMX remote power supply (with CDMX-1 controller), and optional accessories sold separately.
Available Options
Specifications
- Finish: White
- Size: 60"L x 0.7"W x 0.7"H
- Materials: PVC
- Lamp Source: LED
-
Bulb:5 x LED/5W/24V LEDIntegrated LED module
- Total Wattage: 25 watts
- Lamp Color: 2000K-6000K Tunable White
- Delivered Lumens: 1065 lumens
- Lumens/Watt: 42.60
- Beam Angle: 120°
ETL
Wet location
Tunable White
Specification Sheet / Technical Files
